Talaria Sting R MX4 Factory Front Suspension
$4.599,00 Original price was: $4.599,00.$3.399,00Current price is: $3.399,00.
SKU: 1TL-STINGMX4-FORK-BLK
TOP SPEED*: ~85 km/h (52.8 mph)
MAX RANGE*: ~120 kms (75 mi)
WEIGHT: 66 kg (145 lbs)
MOTOR: 4000W
BATTERY: 2700Wh
MAX LOAD: 100 kgs (220 lbs)
MAX GRADE: –
TIRE SIZE: 19 in
Description
THE NEXT GENERATION: TALARIA STING MX4
The new 2023 Talaria Sting R, also known as the MX4, is the latest addition to the Talaria lineup. With an increase in power, updated motor, and a larger capacity battery, the MX4 is a significant improvement from its predecessor, the MX3.
Looking for an electric dirt bike that’s built for performance and thrills? The Talaria STING MX4 is the ride for you! With its CAD-designed lightweight frame, powerful electric motor, and intelligent gear drive for quiet operation, this bike is ready to take on the toughest off-road challenges. Its compact, well-balanced structure makes it easy to maneuver, and with minimal maintenance required, you can focus on the ride, not the upkeep. Don’t settle for anything less than the best – order your Talaria STING MX4 today and experience the ultimate in off-road excitement!
Power Pack
Get ready to experience the power of the Talaria STING R MX4 electric dirt bike! Equipped with an impressive 60V 45Ah lithium-ion power pack, delivering 2700 watt-hours of power, this bike is ready to take on any challenge. And with its easily swappable power packs, you can exchange a fully charged pack in seconds for limitless range. Featuring electric automobile grade LG 21700 lithium-ion battery cells, state-of-the-art programmed BMS, and an optimized internal structure, this battery pack ensures safe and high-performance off-road riding. Don’t wait – order your Talaria STING R MX4 today and take your off-road adventures to the next level!
Frame
Experience fearless off-road riding with the Talaria STING MX4 electric dirt bike. Its cutting-edge engineered frame is purpose-built for even the toughest terrains, with a lightweight and compact design. Constructed using 6061 aluminum alloy and superior forging process, this bike is both strong and durable. Order your Talaria STING MX4 today and enjoy a thrilling off-road adventure!
Controller
The Talaria STING MX4 electric dirt bike comes equipped with a top-notch controller system. This controller is enabled to have an exceptional ability for transient current impact resistance, ultra-strong anti-interference, high-precision EABS voltage control, error inspection, high and low temperature protection, anti-runaway, and smart energy regeneration due to its high quality appropriative hardware, superb layout, and intelligent programming. The rider is guaranteed a powerful, exciting, and safe riding experience that offers a respectable range.
Powertrain
Say goodbye to broken belt anxiety and hello to the ultimate in off-road performance with the Talaria STING R MX4! The customized combination powertrain design is perfect for this lightweight electric MX4 bike, featuring a high-efficiency IPM mid-drive motor with top-class magnet material and advanced processing. With a peak torque output of 45N.m, this motor delivers unbeatable power and performance. And with exquisitely crafted high-accuracy gears, the gearbox runs even quieter and is much more durable than any belt drive system. Don’t wait – order your Talaria STING R MX4 today and experience the ultimate in off-road riding!
Dash
Talaria MX4 Dirt Electric Bike’s dash features an OLED display that displays data clearly while consuming minimal power. With CAN communication, the dash is able to communicate with the battery pack’s BMS and the motor controller to transfer data. With the display menu, you can view information such as top/average speed, range, battery data, riding mode, error codes, and regen levels. Also, the dash allows different settings for different wheel sizes, sprocket sizes, motor regeneration levels, and KM/H and MPH switching to increase compatibility.
Throttle
The Talaria STING MX4 has a unique gear twist structure design to protect the core throttle parts from impact damage. With automobile level encoder technology, the throttle allows for easy acceleration control. It’s the perfect specialized product for any electric off-road bike. Experience the ultimate in off-road performance – order your Talaria STING MX4 today!
Highlights
Whats New (2023 Upgrades)
Specification
SPECIFICATIONS:
Chassis Material: 6061 T4 & T6 Aluminum Alloy
Process Method: Forged by 6000 Tons Pressure
Surface Method: Anodizing
Headlight: LED
Front Fork: Fastace / Factory
Rear Shock: Fastace / Factory
Wheel Size: 19”
Tire: FR 70/100-19 / RR 80/100-19
Top Speed: Approx 85 km/h (52.8 mph) (Factory limited to 32 km/h)
Max. Range: 120 km @ 25 km/h (74.5 miles @ 15.5 mph)
Net Weight: 66 Kg (Including Battery)
Vehicle Dimension: 1880mm x 770mm x 1088mm
Seat Height: 840mm
Wheelbase: 1250mm
Handlebar Length: 760mm
Ground Clearance: 300mm
Motor Type
Motor type: DC IPM (Interior Permanent Magnet)
Mounting Position: Middle of the Frame
Weight: 7 kg
Motor Ext. Diameter: 180mm
Peak Efficiency: 92%
Cooling Method: Air Cooled
Controller
Controller Type: FOC
Weight: 2 kg
Dimension: 248mm x 128mm x 50mm
Peak Efficiency: 92%
Highest Work Temp: 100°
Power System
Nominal Voltage: 60V (DC)
Nominal Power: 4000W
Peak Power: 8000W
Nominal Torque: ≥45 N.M
Transmission
Gear Ratio: 8.35 (44T) / 9.18 (48T)
1st Transmission: Gearbox
2nd Transmission: Chain
Electronic
Battery Pack: 60V 45AH
Battery Size: 170mm x 140mm x 380mm
Battery Weight: 12.8 KG / 28.16 lbs
Battery Cells: LG Brand 21700 Cell (5000 MAH/Cell)
Speedometer: Speed / Battery Level, Voltage, cycle / Odometer
Regen Adjustment: 4 Levels Adjustable in the Speedometer
